Power Source

220 – 240 V AC, or 24 – 30 V DC

Rated Output

60 W

Power Consumption

72 W (EN60065), 150 W (AC operation at rated output),

4 A (DC operation at rated output)

Frequency Response

50 – 20,000 Hz (±3 dB)

Distortion

Under 1% at 1 kHz, 1/3 rated power

Input

MIC 1 – 3: -60 dB*, 600 Ω, balanced, phone jack

AUX 1,2: -20 dB*, 10 kΩ, unbalanced, RCA pin jack

Output

Speaker out: Balanced (floating)

High impedance: 170 Ω (100 V), 83 Ω (70 V)

Low impedance: 4 Ω (15.5 V)

Rec out: 0 dB*, 600 Ω, unbalanced, RCA pin jack

Phantom Power

DC +21 V (MIC 1)

S/N Ratio

Over 60 dB

Tone Control

Bass: ±10 dB at 100 Hz

Treble: ±10 dB at 10 kHz

Muting

MIC 1: Mutes other input signals by 0 – 30 dB attenuation

Indicator

Power, signal, peak

Finish

Panel: ABS resin, black

Case: Steel plate, black

Dimensions

420 (W) × 100.9 (H) × 280.3 (D) mm (16.54″ × 3.97″ × 11.04″)

Weight

7 kg (15.43 lb)
